Clear Corneal Knives
Superior Wound ArchitectureTapered bevels are designed to bend and incise tissue, resulting in a straight incision that is more self-sealing.Blade ProfileThinner blade is designed for minimal effect on astigmatism, and to promote re-epithelialization. Short blade length reduces risk of induced trauma.Unique Patented Width/Depth Indicators1.5mm 1.75mm and 2.0mm act as visual reference when changing planes during an incision. |
Clear Corneal Knife - Top View Clear Corneal Knife - Bottom View |
The BenefitBecause the cutting edge of the Clear Corneal knife does not follow the plane of the blade, the knife compensates for corneal curvature, giving a squarer, more self sealing incision. |
Standard slit knife incision |
Clear Corneal knife incision |
Clear Corneal Knives, Double Bevel
Sharpoint™ clear corneal knives feature tapered facet cutting edges designed to compensate for corneal curvature, creating exact linear incisions. The unique thin blade design and consistent sharpness creates incisions with virtually no tissue drag or distortion. Patented incision width/depth indicators (1.5mm,1.75mm, 2.0mm) are visible on each blade. 6 per box. (U.S. Pat. No. 5,370,652 and 5,217,476) |
||||
Knife |
Blade |
Description |
||
 |
72-1361 E7594 (Oasis®) |
1.3mm | Angled, full handle, 1.0mm width indicator | |
| 72-1361 E7594 (Oasis®) |
1.3mm | Angled, full handle, 1.0mm width indicator | ||
| 72-1661 E7595 (Oasis®) |
1.6mm | Angled, full handle, 1.0mm width indicator | ||
| 72-1661 E7595 (Oasis®) |
1.6mm | Angled, full handle, 1.0mm width indicator | ||
 |
||||
Knife |
Blade |
Description |
||
 |
72-2663 CCR-265AGF (Kai) P-9627B (Oasis®) 52-2663 (Stylus™) |
2.65mm | Angled, full handle, w/depth indicators | |
| 72-2663 CCR-265AGF (Kai) P-9627B (Oasis®) 52-2663 (Stylus™) |
2.65mm | Angled, full handle, w/depth indicators | ||
| 72-2763 E7527 (B+L) 52-2763 (Stylus™) |
2.75mm | Angled, full handle, w/depth indicators | ||
| 72-2763 E7527 (B+L) 52-2763 (Stylus™) |
2.75mm | Angled, full handle, w/depth indicators | ||
| 72-2863 375728 (BD) CCR-28AGF (Kai) P-9628B (Oasis®) E7528 (B+L) 52-2863 (Stylus™) |
2.85mm | Angled, full handle, w/depth indicators | ||
| 72-2863 375728 (BD) CCR-28AGF (Kai) P-9628B (Oasis®) E7528 (B+L) 52-2863 (Stylus™) |
2.85mm | Angled, full handle, w/depth indicators | ||
| 72-3061 375730 (BD) CCR-30AGF (Kai) P-9630B (Oasis®) E7529 (B+L) 52-3061 (Stylus™) |
3.0mm | Angled, full handle, w/depth indicators | ||
| 72-3061 375730 (BD) CCR-30AGF (Kai) P-9630B (Oasis®) E7529 (B+L) 52-3061 (Stylus™) |
3.0mm | Angled, full handle, w/depth indicators | ||
| 72-3263 375732 (BD) P-9632B (Oasis®) E7532 (B+L) 52-3263 (Stylus™) |
3.2mm | Angled, full handle, w/depth indicators | ||
| 72-3263 375732 (BD) P-9632B (Oasis®) E7532 (B+L) 52-3263 (Stylus™) |
3.2mm | Angled, full handle, w/depth indicators | ||
Clear Corneal Knives, Double Bevel
Sharpoint™ clear corneal knives with parallel sides feature center cutting edges with side cutting ability. The unique thin blade design and consistent sharpness creates incisions with virtually no tissue drag or distortion. Patented incision width/depth indicators (1.50mm, 1.75mm, 2.00mm) are visible on each blade. 6 per box. (U.S. Pat. No. 5,370,652 and 5,217,476) |
||||
Knife |
Blade |
Description |
||
 |
72-2635 8065992647 (Alcon®) 09627B (Oasis®) 52-2635 (Stylus™) |
2.65mm | Angled, full handle, w/depth indicators | |
| 72-2635 8065992647 (Alcon®) 09627B (Oasis®) 52-2635 (Stylus™) |
2.65mm | Angled, full handle, w/depth indicators | ||
| 72-2735 8065992747 (Alcon®) E7575 (B+L) 52-2735 (Stylus™) |
2.75mm | Angled, full handle, w/depth indicators | ||
| 72-2735 8065992747 (Alcon®) E7575 (B+L) 52-2735 (Stylus™) |
2.75mm | Angled, full handle, w/depth indicators | ||
| 72-2835 09628B (Oasis®) E7572 (B+L) 52-2835 (Stylus™) |
2.85mm | Angled, full handle, w/depth indicators | ||
| 72-2835 09628B (Oasis®) E7572 (B+L) 52-2835 (Stylus™) |
2.85mm | Angled, full handle, w/depth indicators | ||
| 72-3035 8065993047 (Alcon®) 09630B (Oasis®) 52-3035 (Stylus™) |
3.0mm | Angled, full handle, w/depth indicators | ||
| 72-3035 8065993047 (Alcon®) 09630B (Oasis®) 52-3035 (Stylus™) |
3.0mm | Angled, full handle, w/depth indicators | ||
| 72-3235 8065993447 (Alcon®) 375732 (BD) 09632B (Oasis®) 52-3235 (Stylus™) |
3.2mm | Angled, full handle, w/depth indicators | ||
| 72-3235 8065993447 (Alcon®) 375732 (BD) 09632B (Oasis®) 52-3235 (Stylus™) |
3.2mm | Angled, full handle, w/depth indicators | ||
